| Relevant Dimensions(mm) | Motive Power of CNG Dump Truck 8 × 4 | |||
| Model | Dump Truck 8 × 4 | Engine model | SC12DT320Q3 | WP12NG350E30 |
| Axle base | 1850+4000+1350 | Pattern | Orthostichous, six-cylinder | Orthostichous, six-cylinder |
| Overall length | 11980 | Electric cabinet mixing, spark plug ignition | Electric cabinet mixing, spark plug ignition | |
| Overall width | 2495 | Rated output/speed(kw/r/min) | 235/2200 | 257/2200 |
| Overall height | 3600 | Max torque/speed(Nm/r/min) | 1250/1400 | 1400/1400-1600 |
| Container length | 9600 | Cylinder diameter × stroke(mm) | 114×155 | 126×155 |
| Container width | 2300 | Air inlet method | supercharge inter-cooling | supercharge inter-cooling |
| Container height | 750 | Displacement(L) | 8.82 | 11.59 |
| Overall front suspension | 1370 | Idling speed | 650±25 | 700 |
| Overall rear suspension | 2700 | Cooling method | Water cooling | Liquid cooling |
| Unloading mode | side dumping | Max net power/speed | 233/2200 | 251/2200 |
| Frame height | 314 | Fuel | NG | NG |
| Frame width | 940/850 | Noise | <93 | <93 |
| Front/rear track base | 2065/1860 | Discharge | Euro-3 | Euro-3 |
| Weight Parameters(kg) | Steering System | Clutch System | |||
| Overall mass | 14805 | Diverter | ø100 | Pattern | ø430 Clutch |
| Chassis kerb mass | 10685 | Steering kinetic pump | Liquid pump | Control system | Hydraulic pneumatic control |
| Loading mass (announcement) | 16000 | ||||
| Overall weight (announcement) | 31000 | ||||
| Transmission Performance | Brake System | Other Parameters | |||
| Top speed(km/h) | 75 km/h | Pattern | Double-circuit pneumatic braking | Tire model | 11.00R20 |
| Max grade ability | 30% | Brake type | Drum-type braking | Air tank volume | 960M³ |
| Gearbox model | RT-11509C | Parking braking | Spring-type | Battery capacity | 135 Ah |
| Gearbox gears | 9 | Emergency braking | Spring-type | ||
| Speed ratio of drive axle | 5.73 | ||||
