| Relevant Dimensions(mm) | |
| Type: | CAMC Lightweight Van 8×4 |
| Wheel Base | 1850+4605+1350 |
| Overall Length | 11980 |
| Overall Width | 2500 |
| Overall Height | 3850 |
| Warehouse Length | 9600 |
| Warehouse Width | 2300 |
| Warehouse Height | 600,800 |
| Front Overhang | 1370+75 |
| Rear Overhang | 2805 |
| Frame Ground Clearance | 1128 |
| Frame Height | 278 |
| Frame Width | 940/842(front/rear) |
| Wheelbase | 2065/1860 |
| Power of Lightweight Cargo Truck 8×4 | ||
| Engine Type | SC9DK270Q3B1 | WP10.270E32 |
| Pattern | In-line, Water Coiling, Six-Cylinder | In-line, Water Coiling, Six-Cylinder |
| Oil Feeding System | Inner EGR | Inner EGR |
| Rated Power/Rotate Speed (KW/r/min) | 199/2200 | 199/2200 |
| Max. Torque/Rotate Speed (Nm/r/min) | 1125/1400 | 1100/1200-1600 |
| Cylinder Diameter×Stroke (mm) | 114×144 | 126×130 |
| Admission Method | Inter-Cooling | Inter-Cooling |
| Output Volume (L) | 8.82 | 9.726 |
| Idling Speed | 700±20 | 600±50 |
| Way of Cooling | Water-Cooling | Water-Cooling |
| Max.Net Power/Rotate Speed(KW/r/min) | 195/2200 | 195/2200 |
| Max.Net Power/Rotate Speed Fuel Feeding | 0.166 | 0.202 |
| Noise Db(A) | <93 | <93 |
| Emission | Euro-3 | Euro-3 |
| Weight (kg) of CAMC Van 8×4 | Steering System | Clutch System | |||
| Curb Weight | 12100 | Redirector | ø100 | Type | ø430 Pusher Clutch |
| Chassis Curb Weight | 10100 | Power Steering Pump | Liquid Pump | Control System | Hydraulic Pneumatic Control |
| Carrying Capacity (announcement) | 18705 | ||||
| Total Weight | 31000 | ||||
| Transmission Performance | Brake System of CAMC Van 8×4 | Other Parameters | |||
| Top Speed | 120 km/h | Type | Double-loop Pneumatic Braking | Type of Tires | 11.00-20 |
| Max Gradient | 25% | Type of Brake | Drum Brake | Fuel Tank Capacity (L) | 380L |
| Model of Gearbox | 9JS119B | Parking Brake | Spring Type | Capacity of Batteries (Ah) | 135 Ah |
| Gears | 9 | Emergency Brake | Spring Type | ||
| Drive Axle Ratio | 4.44 | ||||
